Standard boxing ring 5x5 m on 0.5 m platform

Purpose: The ring "Standard" is intended for training and competitions. The ring consists of a metal construction, consisting of individual modular sections, corner posts on which horizontally fixed ropes, well protected by covers along the entire length and treaded cushions in the corners of the ring. The corner cushions are placed on the rope fasteners at the corners of the ring at the joints between them. Four ropes are stretched on each side at 40 cm, 70 cm, 100 cm and 130 cm from the ring surface and connected to each other by two PVC bars 3 to 4 cm wide at equal intervals. The ring is covered by skirts around the perimeter of the ring, covering the sides of the platform. The top of the ring is covered with a plywood (or wooden) boarding with a cushioning material and anti-slip, reinforced PVC fabric on top.

Materials used in ring manufacture: the corner posts are manufactured from round, thick-walled tube with the diameter of at least 100mm and a wall thickness of at least 5mm, with a stiffening frame reinforced along the entire length to reduce static tension and deformation, and with an anti-vibration system to absorb linear vibrations. Includes individual pole cover made from flexible, regulated materials with fixing holes. For injury protection, corner pads filled with PPE in PVC replaceable covers are fitted on the cross-rope joints. Ropes for rings are manually produced in a composite method based on a multi-layer composition: galvanically treated steel rope in a compensator, damped multi-layer filler, reinforced PVC sheath. The fabric is joined by thermo-welding, which guarantees the durability and strength of the seams. Skirts, covers and treads can be labelled, emblems and customer advertisements can be applied. To ensure high regular loads and an extended lifespan, the modular scaffolding elements are fitted with composite universal metal fixings, and the thick-walled profile tubes are stiffened. The canvas of the ring is made of flexible, regulated material and covered with reinforced, high-density PVC fabric. The flooring of the ring is made of imported premium grade plywood or specially treated hardwood planks, which are assembled into a single board. Ladders for easy climbing are included with the ring.

The raw material used in the production of the ring is certified and has the appropriate regulatory documentation. The goods are accompanied by the necessary technical documentation (technical passport, certificate of compliance, conclusion of sanitary epidemiological expertise, etc.).

Ring delivery: the ring is delivered in modular components in order to optimise and simplify assembly by a minimum number of people and easy compact transportation, and to reduce logistics costs. The ring is transported unassembled and packed with protective packaging.

Kit of the ring: metal cantilever frames, plywood or wooden decking, kanvas cover complete with skirts, ropes and covers, rope extensions and covers- protectors, corner protectors, ladders for athletes and referees, jumpers on ropes, rope tensioning system, fixing and technical kit.

Reference Documents: Every ring is checked by the Quality Control Department and a stamp is put on the individual product data sheet. The ring has passed the European and national certifications.

Warranty: The factory provides a full factory warranty and post-warranty service.

Individual order: The equipment can also be tailored to the individual specifications of the customer. All the ring elements can be optionally painted in any colour, or the ring treads, covers and covers can be produced in the colours agreed upon by the customer. The thickness of the canvas can be varied to the customer's specifications, and the ring rope thickness can also be varied.

Storage conditions: The ring must be stored in a dry, heated, folded and horizontal position. The storage room must ensure protection against mechanical and chemical damage, including the effects of aggressive climatic conditions.
